Engine removal

Discussion in '8-valve' started by mk2 nas, Dec 6, 2015.

  1. mk2 nas Paid Member Paid Member

    Joined:
    Jul 30, 2013
    Likes Received:
    82
    Location:
    Northamptonshire
    Hi, big thanks to all help on here,eg running well starts,idles,sounds good for an old engine maybe it's had work previously.
    I think I've been lucky for a sub 100 engine.had the same result on my mk2.two good engines for 200.happy days.

    My 1800 EV I removed took head off bores look good.no scores barely any lip.but it was knocking somewhere.im planning the
    Following.remove Pistons hone bores a bit fit new rings,replace crank shells,new oil pump,and check little ends and replace
    If needed.ive not rebuilt a bottom end before is this enough to achieve a decent spare.that in time will go back in.:o

  2. Jon Olds Forum Junkie

    Joined:
    Jan 28, 2004
    Likes Received:
    487
    Location:
    United Kingdom
    Knocking will prob be big ends, get the sump off. Cranks are rock hard, probably get away with a set of shells, hopefully.
    Jon

  3. mk2 nas Paid Member Paid Member

    Joined:
    Jul 30, 2013
    Likes Received:
    82
    Location:
    Northamptonshire
    Yes was planning on doing the shells only to start with but thought new rings would be a good idea too.
    If the shells have been the problem would they be obviously worn to the eye.???
    Or are we talking micro measurments of wear not visible.
    I've heard of shells losing the surface and going copper like scratches.

  4. mk2 nas Paid Member Paid Member

    Joined:
    Jul 30, 2013
    Likes Received:
    82
    Location:
    Northamptonshire
    Changed all gear linkages today including gearstick base assembly.cant beleive the difference feels like a different car
    Very positive changes.[:D]

  5. Jon Olds Forum Junkie

    Joined:
    Jan 28, 2004
    Likes Received:
    487
    Location:
    United Kingdom
    Shells that look ok in my experience are ok. I have used secondhand rings on secondhand pistons many times, providing the bores aren't shot
    Jon

  6. mk2 nas Paid Member Paid Member

    Joined:
    Jul 30, 2013
    Likes Received:
    82
    Location:
    Northamptonshire
    Oh ok. I will check the big ends although knocking is there it's not that heavy so I'm thinking more
    Likely the little ends making a piston slap maybe.

  7. mk2 nas Paid Member Paid Member

    Joined:
    Jul 30, 2013
    Likes Received:
    82
    Location:
    Northamptonshire
    Started my mk1 today.about the sixth time I've ran it but seemed really lumpy today and stunk of fuel at the exhaust
    Think it may need some adjustments.could something be stuck and over fuelling?.

  8. Finite

    Finite Paid Member Paid Member

    Joined:
    Nov 20, 2004
    Likes Received:
    255
    Location:
    Northamptonshire
  9. mk2 nas Paid Member Paid Member

    Joined:
    Jul 30, 2013
    Likes Received:
    82
    Location:
    Northamptonshire
    Ok it's a strange one ive had it running normally over last two weeks but just today seems lumpy almost like its
    On three cylinders.and ive not adjusted anything.may check spark on all plugs first&timing set up.take it from there.

  10. mk2 nas Paid Member Paid Member

    Joined:
    Jul 30, 2013
    Likes Received:
    82
    Location:
    Northamptonshire
    Lumpy running is sorted just clean everything electrical and is normal now.however ive now got a clutch squeel
    Not all the time .changes with clutch movement.cutch has had new friction plate and t/o bearing pressure plate was left in
    As it looked "good"didn't appear worn with no grooves or lip and good spring tension.im not sure how much g/box oil
    Is in there and I do remember losing some would it cause a squeel if too low.

  11. rubjonny

    rubjonny Administrator Staff Member Admin

    Joined:
    Oct 31, 2003
    Likes Received:
    2,841
    Location:
    Bracknell
    does it only squeel when the pedal is pushed? this points to TO bearing I would say

  12. mk2 nas Paid Member Paid Member

    Joined:
    Jul 30, 2013
    Likes Received:
    82
    Location:
    Northamptonshire
    New t/o bearing,although it could be duff,ive just dumped a litre of g/box oil in and it's stopped!.so don't really know
    What would affected by a low level.

  13. rubjonny

    rubjonny Administrator Staff Member Admin

    Joined:
    Oct 31, 2003
    Likes Received:
    2,841
    Location:
    Bracknell
    if its an 020 box then yeah low oil will probably cause it, as it sits in the 5th housing and should be well lubed I expect

  14. mk2 nas Paid Member Paid Member

    Joined:
    Jul 30, 2013
    Likes Received:
    82
    Location:
    Northamptonshire
    Ok not sure how much was in there I'm suspecting poss a third of what there should have been.meant to have topped
    Up after engine/clutch work but sort of forgot about it.the Haynes reckons 2 litres for a 5spd manual.so my litre plus
    What I think is in there should be enough.dont wanna overfill might do damage.

  15. Jon Olds Forum Junkie

    Joined:
    Jan 28, 2004
    Likes Received:
    487
    Location:
    United Kingdom
    there is a level plug in an 020. fill it until it come out
    low oil level kills boxes
    Jon

    Nige likes this.
  16. mk2 nas Paid Member Paid Member

    Joined:
    Jul 30, 2013
    Likes Received:
    82
    Location:
    Northamptonshire
    Ok,where abouts is the level plug.

  17. Jon Olds Forum Junkie

    Joined:
    Jan 28, 2004
    Likes Received:
    487
    Location:
    United Kingdom
  18. mk2 nas Paid Member Paid Member

    Joined:
    Jul 30, 2013
    Likes Received:
    82
    Location:
    Northamptonshire
    The squeel is back but not as bad.yours thoughts would help.firstly how many things could squeel on clutch transmission.
    My thoughts are.t.o bearing is duff although it's new.the other item I think is a strong possibility is the small centre piece
    On pressure plate that pushrod pushes onto.im absolutly sure its clutch related.
    So far...new friction plate,new bearing,new g/box oil.pressure plate is very good but not new.
    Flywheel is also good.
    Car is ok/driveable but fecking annoying ive gotto get rid of this noise.

  19. rubjonny

    rubjonny Administrator Staff Member Admin

    Joined:
    Oct 31, 2003
    Likes Received:
    2,841
    Location:
    Bracknell
    may as well pull the bearign out to have a look, pull out the pushrod too and check its fitted the right way round as the OE rods differ. pattern ones appear to be the same on both ends though. broke has lots of info on his site linked earlier including rod pictures and measurements :)

  20. mk2 nas Paid Member Paid Member

    Joined:
    Jul 30, 2013
    Likes Received:
    82
    Location:
    Northamptonshire

    Finite likes this.
